The pipe is threaded on both ends with one end featuring a socket and protective plastic cap, while its length can be customized according to the customer's preferences, ranging from 3 meters to 12 meters.
The pipe or tubing can be customized to the customer's desired length, ranging from 3 meters to 12 meters, and features threads on both ends, a socket on one end, and a protective plastic cap on the other.
Client can specify their desired length, ranging from 3 meters to 12 meters, for this pipe or tubing, which is threaded at both ends, socketed on one side, and protected with a plastic cap on the opposite end.
The customer can choose any length between 3 meters to 12 meters for this pipe or tubing, which is threaded at both ends, features a socket on one side, and has protective plastic cap on the other end.
Featuring threaded ends on both sides, a socket on one end, and safeguarded with a plastic cap on the other, this pipe or tubing can be customized to lengths between 3 meters and 12 meters, according to the customer's preferences.
Customers have the option to specify their desired length, ranging from 3 meters to 12 meters, for this pipe or tubing. It features threads on both ends, a socket on one end, and is protected with a plastic cap on the other side.
Customizable in length from 3 meters to 12 meters, this pipe or tubing comes with threads on both ends, a socket on one side, can be customized.
This 5-meter-long pipe is designed with flat and smooth surfaces on both sides, making it ideal for nozzle cleaning applications.
This 5-meter pipe possesses flat surfaces on both ends, optimizing its performance in applications requiring thorough cleaning.
Pipes are manufactured by high frequency induction welding process in a state of art automatic Tube Mill
|
N.B. |
Outside Diameter |
Wall Thickness |
Weight of Black Pipe |
||
|
Plain End |
Screwed & Socketed |
||||
|
mm |
MIN(mm) |
MAX(mm) |
mm |
Kg/M |
Kg/M |
|
8(L) |
13.2 | 13.6 | 1.8 | 0.517 | 0.521 |
| 8(M) | 13.2 | 14.0 | 2.35 | 0.650 | 0.654 |
| 8(H) | 13.2 | 14.0 | 2.9 | 0.769 | 0.773 |
| 10(L) | 16.7 | 17.1 | 1.8 | 0.674 | 0.680 |
| 10(M) | 16.7 | 17.5 | 2.35 | 0.852 | 0.858 |
| 10(H) | 16.7 | 17.5 | 2.9 | 1.02 | 1.03 |
| 15(L) | 21.0 | 21.4 | 2.0 | 0.952 | 0.961 |
| 15(M) | 21.0 | 21.8 | 2.65 | 1.22 | 1.23 |
| 15(H) | 21.0 | 21.8 | 3.25 | 1.45 | 1.46 |
| 20(L) | 26.4 | 26.9 | 2.35 | 1.41 | 1.42 |
| 20(M) | 26.5 | 27.3 | 2.65 | 1.58 | 1.59 |
| 20(H) | 26.5 | 27.3 | 3.25 | 1.90 | 1.91 |
| 25(L) | 33.2 | 33.8 | 2.65 | 2.01 | 2.03 |
| 25(M) | 33.3 | 34.2 | 3.25 | 2.44 | 2.46 |
| 25(H) | 33.3 | 34.2 | 4.05 | 2.97 | 2.99 |
| 32(L) | 41.9.0 | 42.5 | 2.60 | 2.54 | 2.57 |
| 32(M) | 42.0 | 42.9 | 3.20 | 3.10 | 3.13 |
| 32(H) | 42.0 | 42.9 | 4.00 | 3.79 | 3.82 |
| 40(L) | 47.8 | 48.4 | 2.90 | 3.23 | 3.27 |
| 40(M) | 47.9 | 48.8 | 3.20 | 3.56 | 3.60 |
| 40(H) | 47.9 | 48.8 | 4.00 | 4.37 | 4.41 |
Until otherwise specified the pipes are threaded at both ends and socketed at one end and the other side is protected with a plastic cap
Special sea worthy Packaging for Export
1. Each Pipe is coated with antirust paint/varnish
2. Master bundles are warped in HDPE sheets
